BELIMO 22CT-14H
The BELIMO 22CT-14H is a reliable actuator designed to control air and fluid flow in HVAC systems. It provides precise modulation, optimizing system performance and energy efficiency. With its durable design and consistent operation, it is perfect for both commercial and industrial applications requiring continuous, efficient environmental control.
Key Features
- Active 4‑20 mA output signal
- Eight selectable temperature ranges
- Stainless‑steel probe, 50 mm length
- Plenum‑rated cable, 2 m length
- Housing rated IP65 / NEMA 4X
- Wide supply range DC 13.5‑26.4 V
৳ 0.00
Description
Accurate and reliable temperature measurement is vital in building automation, HVAC systems, and critical environmental control zones. The BELIMO 22CT‑14H sensor excels in these applications by offering an active 4‑20 mA output — widely compatible with BMS/PLC interfaces — and eight pre‑selectable measuring ranges (for example –50…50 °C up to 0…250 °C) to match your specific installation. belimo.com+1 The sturdy stainless‑steel 50 mm probe penetrates duct or pipe environments, while the plenum‑rated 2 m cable allows safe routing in air‑handling spaces and ensures compliance with building codes. Thanks to its IP65 / NEMA 4X rated housing, the device withstands dust, condensate and challenging mechanical‑room conditions. belimo.com Compared to basic temperature sensors that offer fixed ranges and weaker protection, the 22CT‑14H brings flexibility, durability, and future‑proof signal compatibility. For your fire‑service panels, parking‑system ventilation or home‑automation HVAC integration (as MSI Agency provides), the 22CT‑14H means fewer variants to stock, simpler wiring and a single sensor that covers multiple use‑cases — reducing time on site, improving reliability, and giving you a professional installation outcome.
Specifications
- Output signal: 4…20 mA, max. load 500 Ω. belimo.com+1
- Measuring ranges selectable (eight options): e.g., –50…50 °C; –10…120 °C; 0…50 °C; 0…250 °C; –15…35 °C; 0…100 °C; –20…80 °C; 0…160 °C. belimo.com+1
- Supply voltage: DC 13.5…26.4 V (nominal 24 V). belimo.com+1
- Power consumption: approx. 0.5 W. hvac.co.th+1
- Probe length: 50 mm; probe diameter: 6 mm. belimo.com+1
- Cable length: 2 m (plenum‑rated). belimo.com
- Housing protection: IP65 (IEC) / NEMA 4X (UL). Müller Automatika+1
- Ambient operating temperature: –35 °C to +50 °C. Medium temperature up to –50 °C to +180 °C (depending on range). hvac.co.th+1
- Accuracy: ±0.5 °C at 21 °C for certain ranges. Long‑term stability approx. ±0.04 °C per year. belimo.com
- Weight: approx. 0.20 kg (type 22CT‑14H) belimo.com
- Electrical connection: Removable spring‑loaded terminal block (max. 2.5 mm²) or cable gland Ø6‑8 mm. hvac.co.th
The BELIMO 22CT‑14H temperature sensor is available in Bangladesh through HVAC & automation equipment distributors. Local pricing depends on import duties, stock availability and order volume — please contact your trusted supplier for a current quote.
