BELIMO Z220S-230
The BELIMO Z220S-230 is a versatile actuator designed to regulate air and fluid flow in HVAC systems. It provides precise modulation, ensuring optimal system performance and energy efficiency. With its reliable operation and rugged construction, it is ideal for commercial and industrial applications that require consistent, high-performance environmental control.
Key Features
- Two-way ¾″ valve for versatile use
- Kvs 2.2 m³/h flow capacity
- 230 V AC powered actuator
- Spring-return for fail-safe operation
- Forged brass body for durability
- Supports water/glycol up to 50%
৳ 0.00
Description
In modern HVAC systems—such as fan-coil units, VAV boxes or zone control applications—precision and reliability of flow control are critical. The BELIMO Z220S-230 fills this need by combining a two-way ¾″ valve body (DN20) with an integrated 230 V AC actuator and spring-return mechanism. This ensures that in case of power loss the valve will return to its safe “closed” state automatically. With a Kvs of 2.2 m³/h it offers appropriate flow for moderate zone loads, reducing the risk of oversizing and enabling better control. The valve body is forged brass, spindle nickel-plated brass, providing long service life and strong resistance to corrosion. It handles both chilled and hot water, including mixes of glycol up to 50 % by volume. Compared to alternatives which may lack spring return, have plastic bodies, or require external actuator mounting, this unit offers a fully integrated, maintenance-free solution. For your fire-service, home-automation or parking ventilation systems via MSI Agency, the Z220S-230 presents a trustworthy, low-energy, high-quality zone valve that supports modern building automation with fewer parts, less installation complexity and greater reliability.
Specifications
- Valve type: 2-way, normally closed. belimo.com+2cdn1.npcdn.net+2
- Size / connection: DN 20 / ¾″ internal thread. belimo.com+1
- Kvs (flow coefficient): 2.2 m³/h. belimo.com+1
- Fluid: Water or water with up to 50 % glycol by volume. cdn1.npcdn.net+1
- Fluid temperature range: 0…93 °C (non-freezing). belimo.com
- Close-off pressure Δps: approx. 344 kPa. cdn1.npcdn.net+1
- Actuator voltage: AC 230 V (for Z220S-230 version). belimo.com+1
- Power consumption (running): 6.5 W; wire sizing: 7 VA. belimo.com+1
- Running time (motor): approx. 13-18 s; spring-return time: approx. 4-5 s. cdn1.npcdn.net+1
- Valve body material: forged brass; spindle: nickel-plated brass. cdn1.npcdn.net+1
- Maintenance: maintenance-free design. cdn1.npcdn.net
- Ambient temperature (actuator): 0…50 °C
For Bangladesh supply, please contact our local distributor for a quotation inclusive of duties, shipping and current currency rates. Competitive pricing and project-support available for your installations.
