Fike 80-093-XXXX 360° Orientation Best Price In BD

Essential guide to Fike 80-093-XXXX 360° Orientation. Learn best practices for design, installation, and maintenance of this crucial fire control system component for optimal performance and enhanced fire safety.

Key Features

  • HFC-227ea 360° nozzle
  • The discharge nozzle size refers to the size of schedule 40 or 80 pipe that it can be connected to.

৳ 0.00

Description

Fike 80-093-XXXX 360° Orientation

The discharge nozzles are made of brass and are available in a 180° and 360° discharge patterns. The nozzles are designed to control the agent flow and to distribute the agent throughout the protected enclosure in a uniform, predetermined pattern and concentration.

Six sizes of discharge nozzles are available, 1/2” (15 mm) through 2” (50 mm). The size refers to the size of schedule 40 or 80 pipe that the nozzle can be connected to. Each nozzle has NPT female threads for connection to the pipe network. When ordering nozzles, orifice size must be specified. The nozzle orifice area is determined by performing a hydraulic calculation using the Fike Engineered Flow Calculation program. Nozzle(s) should not be ordered until the clean agent system pipe network is installed and an “As Built” hydraulic calculation is performed. Nozzle orifice drilling must be done at Fike factory, or at a UL listed nozzle drill station.

The function of the Fike discharge nozzle is to control the agent flow and distribute the agent throughout the protected enclosure in a uniform, predetermined pattern and concentration. Nozzles are made of brass and have the Fike logo forged into two hex flats.

Specifications

  • Product Name: Fike 80-093-XXXX 360° Orientation
  • Nozzles size: 1/2” (15 mm) through 2” (50 mm)
  • Size of schedule: 40 or 80 pipe
  • Discharge patterns: 180° and 360°
  • Maintenance Manual: 80-093-XXXX
