8-CHANNEL RELAY SWITCH | C4-DIN-8RELSW-E
Discover the 8-Channel Relay Switch (C4-DIN-8RELSW-E) for seamless control of multiple devices. Ideal for smart home and automation systems, offering reliability and efficiency.
Key Features
- Controls up to eight high in-rush loads.
- Channel buttons allow for toggling a load on/off.
- Channel status LEDs indicate whether a load is on or off.
- Module Override button allows toggling between the module override scene and all channels off or setting the module override scene to to the current channel’s on/off settings.
৳ 0.00
Description
8-CHANNEL RELAY SWITCH
The C4-DIN-8RELSW-E 8-Channel Relay Switch is a high-performance solution designed for advanced automation and control. Perfect for smart home systems and commercial applications, this relay switch enables seamless management of up to eight independent circuits.
Its DIN-rail mount design ensures easy installation, while the robust build guarantees long-lasting performance. With flexible integration capabilities, the C4-DIN-8RELSW-E supports various devices, making it ideal for lighting, HVAC, and other automated systems.
The Control C4 DIN-Rail 8-Channel Relay Switch controls up to eight high in-rush loads from one module in the Control system. Each channel supports a variety of load types, including incandescent, halogen, electronic low-voltage transformers, magnetic low-voltage transformers, fluorescents, compact fluorescents, LEDs, and motors. Some features are:
- Module Status LED indicates if module power is on with normal operation, off, or in thermal overload.
- Link/Activity LED indicates system link status, communication activity, or firmware update status.
- Reset button can be used for restoring factory defaults or network configuration settings.
- Auxiliary override connection allows a standard line-voltage toggle switch to control the attached lights before the control system is installed or in case the controller malfunctions.
- Module can be installed in either a Control 4- 5- or into a 2-slot panel or into a third-party DIN rail panel.
Experience reliable and efficient control with the C4-DIN-8RELSW-E, the perfect choice for modern automation needs.
Specifications
| Product Name | 8-CHANNEL RELAY SWITCH |
| Model | C4-DIN-8RELSW-E |
| Power requirements | 100-277V AC, 50/60 Hz 240V AC, 50 Hz |
| Line feeds (circuits) | 4 |
| Power consumption | 3.5W |
| Supported load types | Incandescent, halogen, electronic low-voltage transformers (ELV), magnetic low- voltage transformers (MLV), fluorescents, compact fluorescents, LEDs, motors |
| Control communications | Ethernet |
| Operational temperature | 0 to 40 ÌŠC (32 to 104 ÌŠF) |
| Humidity | 5% to 95% non-condensing |
| Storage | -20 to 70 ÌŠC (-4 to 158 ÌŠF) |
| H × W × D | 219 × 115 × 57 mm (8.6 × 4.5 × 2.2 in.) |
| DIN module width | 12M |
| Weight | 1.3 kg (2.9 lb.) |
