HAWKEYE RTC
The HAWKEYE RTC is a high-precision remote temperature controller designed for HVAC systems. It allows users to monitor and adjust temperature settings from a distance, ensuring optimal system performance. Its intuitive interface and real-time feedback enhance energy efficiency and comfort in residential and commercial environments.
Key Features
- Measures humidity, temperature & differential pressure
- Built-in real-time clock (RTC) with battery backup
- RS485 / Modbus RTU communication interface
- IP65 (NEMA 3SX) rated front-panel protection
- 3 programmable alarms with buzzer output
- Compact panel-mount form factor (200×180×31 mm)
৳ 0.00
Description
The HAWKEYE RTC brings comprehensive environmental monitoring to applications where clean‐room control, HVAC performance or critical air-handling data are required. For facilities such as pharmaceutical labs, data-centres or hospitals, keeping track of humidity, temperature and differential pressure is essential for regulatory compliance and operational reliability. This unit solves that need by integrating all three sensing channels (RH, T, DP) alongside a real-time clock for time-stamped logging and event tracking. It communicates with PLCs or SCADA systems via RS485/Modbus RTU, enabling automation and remote supervision. Its IP65 rated front allows it to be mounted even in wash-down or demanding environments, while the stainless steel front-plate (or optionally aluminium) ensures durability in industrial settings. Compared to simpler indicators or generic monitors, the HAWKEYE RTC offers richer features: four-row LED display, programmable alarm thresholds, potential-free AHU digital input, and calibration tracking. In Bangladesh, where environment control and documentation may be subject to inspection, choosing this monitor ensures you have a robust instrument that supports detailed logging, alerts, and long-term reliability. Whether used to monitor HVAC rooms, clean-air zones or production labs, the HAWKEYE RTC is a superior alternative to one-channel sensors or low-spec displays.
Specifications
- Model: HAWKEYE RTC (Clean Room Monitor with RTC) Radix Model Assets Public+2Radix Electrosystems+2
- Inputs: 3 (Relative Humidity, Temperature, Differential Pressure) Imimg+1
- Measurement ranges: RH 0-100 % RH; Temperature −40 °C to +120 °C (user-selectable); DP −199 to 900 Pa or −19.9 to 90.0 mmWC. Radix Model Assets Public+1
- Accuracy: RH ±2 % RH; Temperature ±0.3 °C; DP ±1.5 % of reading ±3 Pa (integral sensors) Radix Model Assets Public+1
- RTC Accuracy: Stand-alone mode ±3–5 seconds per day; when synced via SCADA ±3–10 s/day. Imimg+1
- Display: 4-row, 7-segment LED display (0.56″ / 14.2 mm digits) showing RH, T, DP and time (HH:MM) Imimg+1
- Communication: RS485, isolated, Modbus RTU protocol, baud rate up to ~9600 bps. Imimg+1
- Enclosure / Mounting: Panel-mount (cut-out ~200×180 mm); front depth ~31 mm behind panel. Body MS powder-coated, face-plate SS304 mirror or matt finish. Radix Electrosystems+1
- Protection: IP65 rated front (equivalent NEMA 3SX) for wash-down or harsh ambient usage. radixsensors.com
- Supply Voltage: 85–265 VAC or 20–30 VDC versions available. Power consumption max ~4 W. Radix Electrosystems+1
- Alarm Outputs: 3 open-collector outputs; 6 visual alarm indicators & buzzer. Imimg
- Dimensions: Width 200 mm × Height 180 mm × Depth 31 mm (approx) radixsensors.com+1
Please contact an authorised Radix distributor or industrial automation supplier in Bangladesh for the current landed cost, including shipping, taxes and warranty; price may vary based on configuration, supply chain and exchange rates.
