Microtek 100-Watt Solar Panel Best Price

Explore Microtek 100-watt solar panels. Find information on specifications, pricing, and installation. Discover how to harness solar energy with reliable and efficient Microtek solar panels. Learn about solar energy, renewable energy, and sustainable living.

Key Features

  • Positive Power Tolerance Modules.
  • Highly Classified A-Grade Solar Cells for Lesser Degradation and High Energy.
  • Micro Crack Free Panels-100% EL Tested Before and After Lamination.
  • High Conversion Efficiency based on Leading Innovative Photo Voltaic Technologies.
  • PID Free Modules with Long Term Reliability.

৳ 0.00

Description

Microtek 100-Watt Solar Panel

Microtek: India’s Most Preferred and Awarded Brand Launches Solar PV Modules for a Greener Future

Microtek, renowned as India’s ‘Most Preferred’ and ‘Most Awarded’ brand, has introduced an innovative range of Solar PV Modules to promote sustainable and renewable energy solutions.

The Microtek 10W 12V Multi-Crystalline Solar PV Module stands out as a premium product, reflecting Microtek’s commitment to quality and performance. Microtek 100-Watt Solar Panel modules are crafted using top-grade materials and advanced manufacturing techniques, ensuring they meet the highest industry standards. All materials used are sourced from trusted vendors, carefully selected through rigorous market surveys. Known for their reliability and superior performance, Microtek Solar PV Modules are widely recognized and trusted across the market.

What are Solar PV Modules?

Solar PV (Photovoltaic) Modules are devices made by connecting multiple photovoltaic (PV) cells, also known as solar cells. These cells are primarily constructed using semiconductor materials like crystalline silicon. Microtek 100-Watt Solar Panel modules are designed to capture sunlight and convert it into electrical energy, which can then be used to power residential and commercial spaces.

How do Solar PV Modules Work?

Each PV cell is typically around 12.5 cm to 15 cm square and generates approximately 1 to 2 watts of energy. To enhance the power output, these cells are combined into solar PV modules. When sunlight strikes the PV cells within the module, the energy from light photons is transferred to the semiconductor material, exciting electrons and creating an electric current.

Solar PV modules generally have power ratings ranging from 50W to 350W. Microtek 100-Watt Solar Panel can operate independently or be connected to an electrical grid to form a complete solar PV system, offering efficient and sustainable energy solutions for various applications.

Microtek remains committed to providing high-quality solar solutions, empowering consumers to embrace clean energy and contribute to a greener planet.

  • Anti-Reflective Coating Glass Available.
  • Advance IP67/IP68 Junction Box for long-term weather endurance.
  • RFID Tag Available.
  • Sustain Heavy Wind and Snow Loads (2400Pa and 5400Pa).
  • Excellent Performance in Low Light.
  • Salt Mist, Ammonia, Blowing Sand and Hail Resistant.
  • Ideal for Off-Grid as well as On-Grid Applications.
  • IP67 rated MC4 Compatible Connectors.
  • EVA Encapsulation and Anti Reflection Coating for better Module Protection.

Specifications

Nominal Maximum Power (Pm) 100Watts/12V
Open Circuit Voltage (Voc) 21.90V
Short Circuit Current (Isc) 6.12A
Voltage at Maximum Power (Vmp) 17.96V
Current at Maximum Power (Imp) 5.57A
Maximum System Voltage 1000V
General Info
Length x Width x Thickness (LxWxT) – mm 1010x665x35
Mounting Holes Pitch (Y) – mm 500
Mounting Holes Pitch (X) – mm 630
Solar Cells per Module (Units) / Arrangement 36 / (9 x 4)
Solar Cell Type Multi Crystalline Silicon
Front Cover (Material / Thickness) Tempered & Low Iron Glass / 3.2mm
Encapsulate Ethylene Vinyl Acetate
Frame Material Anodized Aluminum Alloy
Junction Box IP67/IP68 Enclosure with Bypass Diodes

What is the Price of Microtek 100-Watt Solar Panelin Bangladesh?
