Ebalco EM600-LED Electromagnetic Door Lock bracket

Secure your space with the Ebalco EM600-LED Electromagnetic Door Lock bracket. A reliable, durable solution for access control systems.

Key Features

Dual Voltage Selectable (12 VDC or 24 VDC)
Low Current Consumption
Reliable Holding Force
Hall Effect Sensor Monitoring Output
Green/Red LED Indication for EM Lock Status
Durable and Silence Operation

৳ 0.00

Description

Ebalco EM600-LED Electromagnetic Door

The Ebalco EM600-LED bracket is specifically designed to complement the EM600-LED electromagnetic door lock, ensuring robust support and optimal performance. Crafted with precision and durability in mind, this bracket is suitable for various door types and installation scenarios. The Ebalco EM600-LED Electromagnetic Door Lock Bracket is ideal for:

Commercial buildings
Residential complexes
Office spaces
Warehouses

The EBELCO Electromagnetic Lock 600 Series is renowned for its exceptional holding force and outstanding features. This series complies with UL, CE, and PSB standards, ensuring the highest quality and reliability. Manufactured under strict quality control measures, it is designed to consistently meet customer expectations for superior performance and dependability. Including features are:

Cosmeticize Anodized Aluminum Casing

Surge & Spike Protection PCB

Anti-Tamper Jam Nuts

Full Range of Optional Brackets

Anti- Residual Magnetism Kick off Button

Specifications

Brand	BEL
Access Method	ACCESS CONTROL
Holding Force	600 LBS
Ideal For	Sliding Doors
Finish Type	Stainless Steel
Model Name/Number	EM-600 MORTICE
Unlocking Mode	FAIL-SAFE
Features	EM LOCK FOR SLIDING DOORS
Usage/Application	ACCESS CONTROL SYSTEMS
Certification	UL LISTED
Voltage Input	12 VDC / 24 VDC
Current Draw	12V / 480mA ; 24V / 240mA (+- 5%)
Holding Force (Max)	600 lbs (272 kg)
Dry Reed Contact (Max)	100VDC,0.25A,3W
Anti-Rust Surface Treatment	Blue Zinc Plating
Operating Temperature	0~55 Degree C ( 32~131 Degree F)
Operating Humidity	0~95% ( non condensing)
Weight ( Magnet)	1.0 kg (+- 1%)
Dimensions	(L)228x(W)38x(T)27 mm

What is the Price of Ebalco EM600-LED in Bangladesh?

Datasheet
