EXT-T24-D201 Modulating Thermostat with LCD Display

Control your heating and cooling with the EXT-T24-D201 Modulating Thermostat with LCD Display. This advanced thermostat offers precise temperature control, energy efficiency, and user-friendly features like programmable schedules, remote access, and compatibility with smart home systems.

Key Features

  • LCD with green backlight, suits 2-pipe system.
  • Proportional output, DC 2…10V (factory default) / DC 0…10V / 4…20mA (600Ω) / 0…20mA (600Ω).
  • Adjustable P-band, I-time and setpoint range, sleeping mode available.
  • Last status memory function.
  • Low temperature protection, external sensor included.

৳ 0.00

Description

Modulating Thermostat with LCD Display

LCD temperature controller EXT-T24-D201 provides the foundation for modern single room concepts. The probe type sensor is included in the EXT-T24-D201 temperature controller. A modulating thermostat with an LCD display is a modern, efficient, and user-friendly solution for controlling the temperature in your home. Traditional thermostats, modulating models provide precise temperature regulation by adjusting heating or cooling output incrementally, ensuring optimal comfort and energy efficiency.

Benefits of Choosing a Modulating Thermostat

Modulating Thermostat with LCD Display can adjust the output of your HVAC system in small increments. This means your system doesn’t work harder than necessary, resulting in consistent temperatures and reduced energy consumption. The inclusion of an LCD display makes these thermostats easy to read and navigate. The display often includes backlighting for visibility in low-light conditions and detailed menus for setting schedules or viewing system performance.

By modulating energy output, these Modulating Thermostat with LCD Display significantly reduce energy waste. Many models come with energy-saving modes or eco settings that further optimize usage, helping lower utility bills. Many modulating thermostats with LCD displays are compatible with smart home systems. You can control them remotely via smartphone apps, voice commands, or through automation features that adapt to your daily routine.

Whether you’re looking to set a weekly schedule or prefer adaptive temperature adjustments based on your activity, Modulating Thermostat with LCD Display offer various programmable options. A modulating thermostat with an LCD display is more than just a gadget; it’s a smart investment in comfort, energy efficiency, and style. By choosing a model with the right features for your needs, you can enjoy a more comfortable home while saving money and reducing environmental impact.

Specifications

Norminal voltage AC 24V 50/60Hz (±10%, AC 21.6V…29.7V)
Power consumption <1W@AC 24V
Output(s) DC 2…10V (factory default) / DC 0…10V / 4…20mA (600Ω) / 0…20mA (600Ω),
Built-in sensor NTC thermistor, 10kΩ@25°C
External sensor NTC thermistor, probe type 10k@25°C
Temperature range Display : 0…99.5°C
Setpoint : 0…99.5°C, 0.5K per step
Mode On / Off / Sleeping
Cooling / Heating
Proportional band 1K…20K adjustable, 0.5K per step (factory default 2K)
Integral time 10…300 seconds adjustable, 10s per step (factory default 90 seconds)
Display offset ±20K adjustable, 0.1 per step (factory default 0)
Heating setpoint
Cooling setpoint
0…99.5°C adjustable, 0.5°C per step (factory default 35°C)
0…99.5°C adjustable, 0.5°C per step (factory default 5°C)
Sleeping mode setpoint range Cooling : 0…99.5°C (factory default 28°C)
Heating : 0…99.5°C (factory default 7°C)
Low temperature protection When thermostat is switched off and ambient temperature < 5°C, thermostat automatically starts in

heating mode until ambient temperature rise to 7°C.

Connection Screw terminals, maximum 1.0mm2 or 18 AWG
Ambient humidity Max. 90% RH, non-condensing
Body material PC + ABS retardant material
Weight 225g
Dimensions (LxWxH) 86 x 86 x 23mm
Mounting Wall mounted, holes separate 60mm vertically, 2x screws provided
Degree of protection IP20
Agency approval CE mark compliant to EMC Directive
External sensor
Sensing Element NTC Thermistor, 10 kΩ@25oC
Range -40°C…105°C
Maximum Length of Connecting Wires 1.5 m
Ambient / Storage Temperature Limits -10°C…40°C (avoid air corrosion or sunlight)
Ambient / Storage Humidity ≤75% RH

What is the Price of Modulating Thermostat with LCD Displayin Bangladesh?

Datasheet
